1. Танилцуулга
This manual provides essential instructions for the safe and effective use of your new Generic replacement power adapter. This charger is designed specifically for BSNAW X8-Pro, N504, N505, and Y5 cordless vacuum cleaners that utilize a 22.2V li-ion battery. Please read this manual thoroughly before use and retain it for future reference.
2. Бүтээгдэхүүн дууссанview
The Generic vacuum charger is a replacement power adapter designed to provide reliable charging for compatible cordless vacuum cleaners. It features built-in safety protections to ensure secure operation.
Image 1: The Generic vacuum charger, showing its compact design and power plug.
3. Тохиромжтой байдал
It is crucial to verify the compatibility of this charger with your vacuum cleaner before use. Incorrect voltage or connector type can damage your device.
3.1 Compatible Models and Battery Types
- Тохиромжтой: BSNAW X8-Pro, N504, N505, Y5 cordless vacuum cleaners.
- Зайны төрөл: Specifically designed for 22.2V li-ion batteries (6-cell configuration).
Image 2: Visual guide indicating compatibility with 21.6V / 22.2V 6-cell li-ion batteries and incompatibility with 25.2V / 25.9V / 29.6V li-ion batteries. Always check your vacuum's battery label for details.
3.2 Power Output Specifications
This charger provides a specific output voltage. Please check the power specifications on your original charger label or vacuum cleaner's manual to ensure a match.
- Оруулах: 100-240V ~ 50/60Hz
- Гаралт: 27V (compatible with 26V) at 0.5A
Image 3: Diagram showing compatible output voltages (27V, 26.5V, 26V at 0.5A) and incompatible voltages (30/31V, 36V, 19V). Verify your device's power requirements.
3.3 Incompatibility
This charger is NOT compatible with BSNAW K5 Y501 25.9V li-ion cordless vacuums that require a 30V charger.
4. Техникийн үзүүлэлтүүд
| Онцлог | Дэлгэрэнгүй |
|---|---|
| Оролтын хэмжээtage | 100-240V хувьсах гүйдэл, 50/60Гц |
| Гаралтын ботьtage | 27V (Compatible with 26V) |
| Одоогийн үнэлгээ | 0.5 Amps |
| Холбогч төрөл | Баррель холбогч |
| Кабелийн урт | 5.9 ft (approximately 1.8 meters) |
| Бүтээгдэхүүний хэмжээс | 2.8"D x 1.8"W x 2"H (Adapter body) |
| Зүйлийн жин | 3.52 унц |
| Аюулгүй байдлын гэрчилгээ | FCC |
Image 4: Diagram illustrating the physical dimensions of the adapter body and the cable length.
Зураг 5: Хөндлөн огтлол view of the charging cable, highlighting the flexible PVC jacket and copper wire construction.
5. Safety Protection Features
This charger incorporates an intelligent chip to provide multiple layers of safety protection during operation:
- Боть гаруйtage Хамгаалалт: Хэт их хэмжээний эвдрэлээс сэргийлнэtage.
- Одоогийн хэт хамгаалалт: Хэт их гүйдлийн урсгалаас хамгаална.
- Хэт цэнэгийн хамгаалалт: Батерейг хэт цэнэглэхээс хамгаалдаг.
- Богино залгааны хамгаалалт: Богино холболтын үед автоматаар унтардаг.
- Over Loading Protection: Хэт их ачааллаас үүдэлтэй гэмтлээс сэргийлдэг.
- Over Heating Protection: Хэт халалтыг хянаж, урьдчилан сэргийлдэг.
Image 6: Icons representing the various safety protection features integrated into the charger.
6. Тохиргоо ба холболт
- Тохиромжтой эсэхийг шалгах: Before connecting, re-confirm that your vacuum cleaner model (BSNAW X8-Pro, N504, N505, Y5) and battery type (22.2V li-ion) match the charger's specifications.
- Вакуум системд холбогдох: Insert the barrel connector of the charger firmly into the charging port of your cordless vacuum cleaner.
- Цахилгаан залгуурт холбогдох: Plug the charger's AC plug into a standard 100-240V wall outlet.
- Цэнэглэх үзүүлэлт: Observe the charging indicator light on your vacuum cleaner (if available) to confirm that charging has begun.
Image 7: A cordless vacuum cleaner connected to a wall outlet via the charger, illustrating the typical charging setup.
7. Ашиглалтын заавар
Once connected, the charger will automatically begin charging the vacuum's battery. The charging time will vary depending on the battery's current charge level and capacity. Refer to your vacuum cleaner's original manual for specific charging duration guidelines.
- Хэрэв кабель эсвэл холбогч гэмтсэн бол цэнэглэгчийг бүү ашиглаарай.
- Ensure the charger is placed in a well-ventilated area during charging.
- Unplug the charger from the wall outlet when not in use or when the battery is fully charged.
8. Засвар үйлчилгээ
- Цэнэглэгчийг цэвэр, хуурай байлга. Чийг эсвэл хэт өндөр температурт өртөхөөс зайлсхий.
- Do not attempt to open or repair the charger. Refer to qualified service personnel if issues arise.
- Цэнэглэгчийг ашиглаагүй үед сэрүүн, хуурай газар хадгална.
9. Алдаа засах
9.1 Vacuum Not Charging
- Холболтуудыг шалгах: Ensure the charger is securely plugged into both the vacuum and the wall outlet.
- Цахилгаан залгуурыг баталгаажуулах: Ханын залгуур ажиллаж байгаа эсэхийг шалгахын тулд өөр төхөөрөмжөөр шалгана уу.
- Цэнэглэгчийг шалгах: Check the charger cable and connector for any visible damage. Do not use if damaged.
- Батерейны нөхцөл: Rechargeable batteries typically last 1-3 years. If your vacuum's battery no longer holds a charge, it may indicate natural battery depletion rather than a charger malfunction. A voltage tester can help diagnose if it's a battery aging issue or a device failure.
9.2 Цэнэглэгчийн хэт халалт
- Unplug the charger immediately.
- Ensure the charger is in a well-ventilated area, away from direct sunlight or heat sources.
- Хэрэв хэт халалт үргэлжилсээр байвал хэрэглээгээ зогсоож, дэмжлэгтэй холбогдоно уу.
10. Баталгаат хугацаа ба дэмжлэг
Энэ бүтээгдэхүүн нь хамт ирдэг 1 жилийн үйлдвэрлэгчийн баталгаа. For warranty claims or technical support, please contact the seller or manufacturer directly. Please retain your proof of purchase for warranty validation.
For further assistance, refer to the contact information provided with your purchase or visit the manufacturer's official webсайт.
