Generic Instant Hot Water Dispenser Countertop 3.5L

1. Аюулгүй ажиллагааны чухал заавар

Төхөөрөмжийг ашиглахаасаа өмнө бүх зааврыг анхааралтай уншиж, цаашид лавлах зорилгоор хадгална уу. Эдгээр зааврыг дагаж мөрдөхгүй байх нь цахилгаан цочрол, гал түймэр эсвэл ноцтой гэмтэл учруулж болзошгүй.

• Ensure the appliance is placed on a stable, flat, heat-resistant surface, away from edges.
• Төхөөрөмж, цахилгааны утас, залгуурыг ус болон бусад шингэнд дүрж болохгүй.
• Keep out of reach of children. This appliance features a child lock function to prevent accidental dispensing.
• Усны саванд зөвхөн цэвэр, ундны ус хэрэглээрэй.
• Цахилгааны утас, залгуур гэмтсэн, эсвэл төхөөрөмж нь буруу ажиллаж, ямар нэгэн байдлаар гэмтсэн бол төхөөрөмжийг ажиллуулж болохгүй.
• Цэвэрлэх, дүүргэх эсвэл ашиглахгүй байх үедээ төхөөрөмжийг үргэлж цахилгааны залгуураас салгаж байгаарай.
• The appliance is made from BPA-free, food-grade materials for your safety.

2. Бүтээгдэхүүн дууссанview

The Generic Instant Hot Water Dispenser provides on-demand hot water with adjustable temperature and volume settings. Its compact design and user-friendly interface make it ideal for various hot beverage preparations.

2.1 Бүрэлдэхүүн хэсэг

• Main Unit with Dispensing Spout
• Large Color LED Display / Control Panel
• Removable Water Tank (3.5L / 0.92 Gallon) with Handle
• Дуслын тавиур
• Цахилгааны утас

2.2 Бүтээгдэхүүний диаграмм

Refer to the image below for a visual representation of the dispenser's main parts.

Зураг 1: Урд view of the Generic Instant Hot Water Dispenser. It shows the main unit with a black finish, a large color LED display on the front, a dispensing spout, and a removable water tank on the back. A drip tray is visible at the base.

3. Тохиргоо

3.1 Савлах ба байрлуулах

1. Carefully remove all packaging materials from the dispenser.
2. Place the dispenser on a clean, dry, stable, and heat-resistant countertop. Ensure there is adequate space around the unit for ventilation.
3. Insert the drip tray into its designated slot at the base of the dispenser.

3.2 Анхны цэвэрлэгээ

1. Remove the water tank from the back of the unit by lifting it using its handle.
2. Wash the water tank and drip tray with warm, soapy water. Rinse thoroughly and dry.
3. Үндсэн нэгжийн гадна талыг зараар арчихamp даавуу. Зүлгүүрийн цэвэрлэгч хэрэглэж болохгүй.
4. Reattach the water tank to the main unit.

3.3 Усны савыг дүүргэх

1. Fill the water tank with clean, potable water up to the MAX fill line. Do not overfill.
2. Ensure the water tank is securely placed back on the unit.

4. Ашиглалтын заавар

4.1 Асаах

1. Цахилгааны утсыг газардуулсан цахилгааны залгуурт холбоно уу.
2. The color LED display will illuminate, indicating the dispenser is in standby mode.

4.2 Температурыг сонгох

The dispenser offers 7 preset temperature settings for various beverages:

• 77°F (Normal): Room temperature water.
• 113°F (Baby Formula): Ideal for preparing baby formula.
• 130°F (Honey): Suitable for dissolving honey.
• 150°F (Scented Tea): Perfect for delicate scented teas.
• 185°F (Coffee): Optimal for brewing coffee.
• 195°F (Tea): Great for most black and herbal teas.
• 212°F (Boiling): For instant noodles, boiling tea, or sterilization.

To select a temperature, touch the temperature icon on the LED display and cycle through the options until your desired temperature is shown.

4.3 Selecting Volume

Choose from 8 volume settings to dispense the precise amount of water:

• 5 унц
• 6 унц
• 8 унц
• 10 унц
• 12 унц
• 14 унц
• 15 унц
• 17 унц

To select a volume, touch the volume icon on the LED display and cycle through the options until your desired volume is shown.

4.4 Ус түгээх

1. Place your cup or mug on the drip tray, centered under the dispensing spout.
2. Ensure the water tank is filled and the desired temperature and volume are selected.
3. Press the 'Dispense' button on the LED display. The dispenser will rapidly heat and dispense the selected volume of water.
4. Water dispensing will stop automatically once the selected volume is reached. You can manually stop dispensing at any time by pressing the 'Dispense' button again.

4.5 Хүүхдийн түгжээний функц

To activate the child lock, press and hold the child lock icon on the display for a few seconds. Once activated, the dispenser will not dispense water until the child lock is deactivated. To deactivate, press and hold the child lock icon again.

5. Засвар үйлчилгээ

5.1 Cleaning the Water Tank and Drip Tray

1. Диспенсерийг тэжээлийн залгуураас салга.
2. Усны сав болон дуслын тавиурыг салга.
3. Wash them with warm, soapy water and a soft sponge. Rinse thoroughly and dry completely before reassembling.
4. It is recommended to clean these parts weekly, or more frequently with heavy use.

5.2 Гадна талын цэвэрлэгээ

1. Диспенсерийн гадна талыг зөөлөн арчиж, damp даавуу.
2. Do not use harsh chemicals, abrasive cleaners, or scouring pads, as these can damage the surface.

5.3 Хатаах

Over time, mineral deposits (limescale) can build up inside the dispenser, affecting performance. Descale the unit every 1-3 months, depending on water hardness and usage.

1. Unplug the dispenser and empty the water tank.
2. Fill the water tank with a descaling solution (e.g., a mixture of white vinegar and water, or a commercial descaling agent designed for water heaters) according to the product's instructions.
3. Place a large heat-resistant container under the dispensing spout.
4. Plug in the dispenser and run several cycles at the highest temperature setting until the water tank is empty.
5. Rinse the water tank thoroughly and refill with fresh, clean water.
6. Run 2-3 full cycles with fresh water to flush out any remaining descaling solution.

6. Алдаа засах

If you encounter any issues with your dispenser, please refer to the table below for common problems and solutions.

7. Техникийн үзүүлэлтүүд

8. Баталгаат хугацаа ба дэмжлэг

This product comes with a standard manufacturer's warranty. For specific warranty details, please refer to the documentation included with your purchase or contact the retailer. If you require technical support or have questions not covered in this manual, please contact the customer service department of your retailer.
