GoPro HD Hero 960 Action Camera User Manual

Танилцуулга

This manual provides essential information for the proper setup, operation, and maintenance of your GoPro HD Hero 960 action camera. Please read these instructions carefully before using your device to ensure optimal performance and longevity.

Image: The GoPro HD Hero 960 camera, enclosed in its clear waterproof housing, ready for use.

Багцын агуулга

Таны багцад бүх зүйл байгаа эсэхийг шалгана уу:

• GoPro HD Hero 960 Camera
• Усны хамгаалалттай орон сууц
• Цэнэглэдэг лити-ион батерей
• Муруй наалдамхай бэхэлгээ
• Хавтгай наалдамхай бэхэлгээ
• Helmet Front Mount
• Толгойamp-Style Head Strap
• Түргэн суллагддаг түгжээ
• USB кабель
• Composite Video Cable (RCA)
• Бүрэлдэхүүн хэсэг видео кабель
• Мини Tripod
• Алсын удирдлага

Зураг: цогц view of the GoPro HD Hero 960 camera and its various included accessories, such as cables, mounts, and a mini tripod, spread out on a white surface.

Тохиргоо

1. Батерей суурилуулах, цэнэглэх

1. Open the camera's rear door.
2. Insert the included Lithium-Ion battery, ensuring correct orientation.
3. Close the rear door securely.
4. Connect the camera to a USB power source using the provided USB cable to charge the battery. A full charge provides approximately 2.5 hours of recording time.

2. SD карт оруулах

1. With the camera powered off, open the rear door.
2. Insert a standard SD card (up to 32GB recommended for 9 hours of storage) into the SD card slot until it clicks into place.
3. Арын хаалгыг хаа.
4. Жич: Use a Class 4 or higher SD card for optimal video recording performance.

3. Attaching Mounts

The GoPro HD Hero 960 comes with several mounting options:

• Adhesive Mounts (Curved/Flat): These mounts are designed for semi-permanent attachment to surfaces like helmets or vehicles. Ensure the surface is clean and dry before applying. Press firmly for 30 seconds and allow 24 hours for the adhesive to cure before use.
• Helmet Front Mount: Attaches to the front of a helmet, allowing for a forward-facing perspective.
• Толгойamp-Style Head Strap: Worn directly on the head or over a helmet for a head-level point-of-view.

Image: The GoPro HD Hero 960 camera securely attached to the side of a white helmet, demonstrating a common mounting configuration for action sports.

Image: The GoPro HD Hero 960 camera attached to a red baseball cap with a head strap, illustrating another versatile mounting option for hands-free recording.

Ашиглалтын заавар

1. Асаах/унтраах

• To power on, press and hold the Power/Mode button until the camera turns on.
• To power off, press and hold the Power/Mode button until the camera turns off.

2. Видео бичлэг хийх

• Press the Power/Mode button repeatedly to cycle through modes until the video icon is displayed.
• Press the Shutter/Select button to start recording. The red LED will flash.
• Бичлэгийг зогсоохын тулд Хөшиг/Сонгох товчийг дахин дарна уу.
• The camera supports 960p (1280x960) and 720p video resolutions, recorded in H.264 (MPEG-4) format.

3. Зураг авах

• Press the Power/Mode button repeatedly to cycle through modes until the photo icon is displayed.
• Press the Shutter/Select button to take a single 5-megapixel photo.
• The camera also supports interval shooting (2 to 60 seconds for up to 2.5 hours), self-timer, and 'triple shot' modes. Refer to the on-screen menu for selecting these options.

4. Underwater Use

The included waterproof housing allows the camera to be used safely up to a depth of 180 feet (55 meters). Ensure the housing is properly sealed before submerging the camera.

Image: The GoPro HD Hero 960 camera, encased in its waterproof housing, attached to the side of an aquarium, demonstrating its capability for underwater or water-adjacent recording.

Засвар үйлчилгээ

• Цэвэрлэгээ: After use, especially in saltwater, rinse the camera and housing with fresh water and dry thoroughly. Use a soft, lint-free cloth for cleaning the lens.
• Орон сууцны үйлчилгээ: Regularly inspect the waterproof housing's O-ring for dirt, sand, or damage. Clean the O-ring and apply a thin layer of silicone grease if necessary to maintain the seal.
• Хадгалах: Store the camera and accessories in a cool, dry place away from direct sunlight.
• Батерейны арчилгаа: For long-term storage, charge the battery to approximately 50% and remove it from the camera.

Алдааг олж засварлах

• Камер асахгүй байна: Ensure the battery is charged and correctly inserted. Try connecting to a power source to see if it powers on.
• Видео/Зургийн чанар муу:
  • Бага гэрэл: The HD Hero 960 performs best in bright, daylight conditions. Footage in low light may appear grainy or noisy.
  • Бүдгэрсэн зургууд: Hold the camera very still for a second after pressing the shutter button to avoid blur, especially in challenging lighting.
  • Underwater Blur: The standard waterproof housing has a curved lens which can cause blur underwater. For clearer underwater footage, consider purchasing an aftermarket housing with a flat lens.
  • Усны цэгүүд: Always wipe the waterproof lens clean and dry before recording or taking photos, especially after being in water, to prevent water spots on your media.
• Vibration Noise in Recordings: If you experience rattling or vibration noises, ensure the camera is securely fastened in its housing and mount. Sometimes, inserting a small piece of paper or foam into the housing can help dampчичиргээ.
• SD картын алдаа: Ensure the SD card is properly inserted and formatted. Use a high-speed SD card (Class 4 or higher) for reliable recording.

Үзүүлэлтүүд

Баталгаат хугацааны мэдээлэл

Specific warranty details for the GoPro HD Hero 960 are not provided in this manual. Please refer to the original product packaging or visit the official GoPro webхамгийн сүүлийн үеийн баталгаат мэдээллийг авах сайт.

Дэмжлэг

For further assistance, technical support, or to explore additional accessories, please visit the official GoPro support webсайт:

GoPro дэмжлэг Webсайт

Бүтээгдэхүүний албан ёсны видеонууд

No official product videos from the seller were found in the provided data for direct embedding in this manual.
