Vivitar 550 FD Speedlite Auto Thyristor Flash User Manual

1. Танилцуулга

The Vivitar 550 FD Speedlite is an external flash unit designed to provide additional illumination for photography. This flash features an auto thyristor system for automatic exposure control and can also be operated in manual mode. It is compatible with cameras equipped with a standard hot shoe mount, including many Canon, Nikon, and Sony models. This manual provides instructions for the proper setup, operation, and maintenance of your Vivitar 550 FD Speedlite.

2. Бүтээгдэхүүний онцлог

• Dedicated Flash: Designed for specific camera systems to ensure proper synchronization.
• Automatic Flash Range: Operates effectively within a range of 3 to 40 feet (approximately 0.9 to 12 meters).
• Auto Thyristor: Automatically adjusts flash output for correct exposure based on ambient light and camera settings.
• Bounce Functionality: Allows the flash head to be angled for indirect lighting, reducing harsh shadows.
• Эрчим хүчний эх үүсвэр: Ашиглахад 4 АА батерей шаардлагатай.

3. Тохиргоо

3.1. Зай суурилуулах

The Vivitar 550 FD Speedlite requires four (4) AA batteries for power. Ensure batteries are inserted with correct polarity.

1. Locate the battery compartment cover, typically on the side or back of the flash unit.
2. Open the cover and insert four fresh AA batteries, matching the positive (+) and negative (-) terminals as indicated inside the compartment.
3. Зайны тасалгааны тагийг сайтар хаа.

Зураг 1: Хажуу тал view of the Vivitar 550 FD Speedlite, showing the general form factor and potential battery compartment location.

3.2. Камертаа флэш суурилуулах

The flash unit is designed to attach to a camera's standard hot shoe mount.

1. Камер болон флэш хоёулаа унтарсан эсэхийг шалгаарай.
2. Флэш суурилуулах хөлийг камерын халуун гутал руу шургуулна уу.
3. Secure the flash by rotating the locking ring or tightening the locking screw on the flash unit until it is firmly attached. The flash features a "LOCK" indicator for secure attachment.

Зураг 2: Дээд тал view of the Vivitar 550 FD Speedlite, illustrating the hot shoe mount and locking mechanism.

4. Ашиглалтын заавар

4.1. Хяналтуудview

Familiarize yourself with the controls on the flash unit:

Зураг 3: Урд view of the Vivitar 550 FD Speedlite, highlighting the control panel.

• POWER унтраалга: Turns the flash unit on or off.
• FILM SPEED / ISO Dial: Sets the film speed or ISO sensitivity.
• AUTOMATIC / MANUAL Selector: Switches between automatic and manual flash modes.
• f/STOP / RANGE Dial: In automatic mode, this sets the aperture and corresponding flash range. In manual mode, it may indicate guide number related settings.
• AUTO OK Indicator: Lights up when the flash has achieved correct exposure in automatic mode.
• READY / TEST Button: Lights up when the flash is fully charged and ready to fire. Pressing it fires a test flash.
• C/R Switch: Likely a control for specific camera compatibility or mode.
• TTL A1/A2/M Selector: Selects between different automatic (A1, A2) or manual (M) modes, potentially related to TTL (Through-The-Lens) metering if supported by the camera.

4.2. Automatic Mode Operation

In automatic mode, the flash's built-in thyristor sensor measures the light reflected from the subject and automatically cuts off the flash output when sufficient light has been provided for correct exposure.

1. Attach the flash to your camera and power on both devices.
2. -г тохируулах AUTOMATIC / MANUAL selector to "AUTOMATIC".
3. -г тохируулах FILM SPEED / ISO dial to match your camera's ISO setting.
4. Select an appropriate f/stop on the flash using the f/STOP / RANGE dial. This will also indicate the effective flash range. Set your camera's aperture to match this f/stop.
5. -г хүлээнэ үү READY / TEST indicator to light up, signifying the flash is charged.
6. Take your photograph. The AUTO OK indicator will light briefly after the flash fires if the exposure was correct.

4.3. Гарын авлагын горимын ажиллагаа

In manual mode, the flash fires at full power, and exposure is controlled by your camera's aperture and shutter speed settings.

1. Attach the flash to your camera and power on both devices.
2. -г тохируулах AUTOMATIC / MANUAL selector to "MANUAL".
3. Consult the flash's guide number (usually found in a separate table or on the unit itself) to determine the correct aperture for a given distance and ISO.
4. Set your camera's aperture and shutter speed accordingly.
5. -г хүлээнэ үү READY / TEST indicator to light up.
6. Take your photograph.

4.4. Үсрэлтийн гэрэл

The Vivitar 550 FD Speedlite supports bounce flash, allowing you to direct the light indirectly off a ceiling or wall for softer, more natural illumination.

1. Gently tilt the flash head upwards or to the side to bounce the light.
2. Adjust camera settings as needed for the increased light path and diffusion.

Зураг 4: Өнцөг view of the Vivitar 550 FD Speedlite, demonstrating the ability to tilt the flash head for bounce photography.

5. Засвар үйлчилгээ

• Цэвэрлэгээ: Флэш төхөөрөмжийн гадна талыг зөөлөн, хуурай даавуугаар цэвэрлэ. Зөрүүд шороонд бага зэрэг damp cloth can be used, followed by a dry cloth. Do not use strong solvents or abrasive cleaners.
• Батерейны арчилгаа: Remove batteries if the flash will not be used for an extended period to prevent leakage and corrosion.
• Хадгалах: Флэшийг нарны шууд тусгал, хэт температураас хол, сэрүүн, хуурай газар хадгална.
• Халуун гутлын холбоо барих хаяг: Камертай зөв холбогдохын тулд халуун гутлын контактуудыг цэвэр, хог хаягдлаас цэвэр байлгаарай.

6. Алдаа засах

7. Техникийн үзүүлэлтүүд

• Загвар: 550 FD
• Брэнд: Амьд
• Үйлдвэрлэгч: ВИВАР
• Эрчим хүчний эх үүсвэр: 4 AA batteries (Note: Product specifications also mention "2 AA batteries required." in some places, but "4 AA" is more consistent with typical flash units and feature bullets. User should verify.)
• Automatic Flash Range: 3 - 40 ft. (0.9 - 12.2 m)
• Flash синк хийх хурд: 1/250 секунд
• Тохиромжтой бэхэлгээ: Standard Hotshoe (Canon, Nikon, Sony compatible)
• Өнгө: Өдрийн гэрэл
• Бүтээгдэхүүний хэмжээ: 6.3 x 3.4 x 2.6 инч (16 x 8.6 x 6.6 см)
• Барааны жин: 0.353 ounces (approximately 10 grams) - Note: This weight seems unusually low for a flash unit and may be a data entry error. Actual weight may be higher.

8. Баталгаат хугацаа ба дэмжлэг

Specific warranty information for the Vivitar 550 FD Speedlite is not provided within this manual. For details regarding warranty coverage, technical support, or service, please refer to the documentation included with your purchase or contact Vivitar customer service directly.
