1. Танилцуулга
Thank you for choosing the HYCHIKA 3.6V Cordless Screwdriver. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your new tool. Please read these instructions carefully before use and retain them for future reference.
2. Аюулгүй ажиллагааны заавар
Гал түймэр, цахилгаанд цохиулах, гэмтэх эрсдэлийг бууруулахын тулд аюулгүй байдлын үндсэн арга хэмжээг үргэлж дагаж мөрдөөрэй.
Цахилгаан хэрэгслийн ерөнхий аюулгүй байдал
- Ажлын талбайн аюулгүй байдал: Ажлын байраа цэвэр, гэрэлтүүлэг сайтай байлга. Эмх замбараагүй эсвэл харанхуй газар осол аваар гарахыг өдөөдөг.
- Цахилгааны аюулгүй байдал: Цахилгаан хэрэгслийг бороо, нойтон нөхцөлд бүү тавь. Цахилгаан хэрэгсэлд ус орох нь цахилгаанд цохиулах эрсдэлийг нэмэгдүүлнэ.
- Хувийн аюулгүй байдал: Always wear appropriate personal protective equipment, such as safety glasses. Dress properly; avoid loose clothing or jewelry that can get caught in moving parts.
- Хэрэгслийн хэрэглээ ба арчилгаа: Цахилгаан хэрэгслийг хүчээр бүү хий. Хэрэглээнд тохирох цахилгаан хэрэгслийг ашигла. Аливаа тохируулга хийх, дагалдах хэрэгслийг солих, цахилгаан хэрэгслийг хадгалахын өмнө залгуурыг тэжээлийн эх үүсвэрээс салгаж, батерейг цахилгаан хэрэгслээс салга.
Батерейны аюулгүй байдал
- Only charge the battery with the charger specified by the manufacturer.
- Do not incinerate the battery pack even if it is severely damaged. Batteries can explode in a fire.
- Зайны терминалуудад богино холболт үүсгэж болохгүй.
3. Багцын агуулга
Савлахдаа бүх зүйл байгаа эсэхийг шалгана уу:
- 1 x HYCHIKA 3.6V Cordless Screwdriver
- 36 x Accessories (various screwdriver bits, sockets, HSS drill bit, extension bar)
- 1 x цэнэглэгч адаптер
- 1 x USB цэнэглэгч кабель
- 1 x Зааварчилгааны гарын авлага
- 1 х хадгалах хайрцаг
Зураг 3.1: Included accessories, featuring various bit types and sizes, sockets, an HSS drill bit, and an extension bar for diverse applications.
4. Бүтээгдэхүүн дууссанview
Familiarize yourself with the components of your HYCHIKA Cordless Screwdriver.
Зураг 4.1: This diagram identifies key components: Self-locking chuck, Rotating button, Front LED light, Forward/Reverse buttons, On/Off switch, USB port, Charging indicator, Rear flashlight.
Гол онцлогууд:
- 6 Nm Max Torque: Provides sufficient power for various screwing and light drilling tasks.
- 2.0Ah Lithium-ion Battery: Offers long-lasting power and durability.
- Эргэдэг бариул: Allows adjustment from a straight to a pistol grip for versatility and access in tight spaces.
- Front LED Light & Rear Flashlight: Illuminates the work area and provides general utility lighting.
- Quick-Release Chuck: Enables fast and easy bit changes.
Зураг 4.2: The screwdriver's handle can rotate for different working angles, enhancing usability in various situations.
5. Тохиргоо
Inserting Screwdriver Bits/Sockets
- Халив унтраалттай, урагш/ухраах унтраалга нь төвийг сахисан (түгжигдсэн) байрлалд байгаа эсэхийг шалгаарай.
- Pull the quick-release chuck forward.
- Insert the desired 6.35mm hex shank bit or socket firmly into the chuck.
- Release the chuck to lock the bit in place. Gently pull on the bit to ensure it is securely fastened.
- For longer reach, attach the extension bar first, then insert the bit into the extension bar.
6. Ашиглалтын заавар
Powering On/Off and Direction Control
- To turn the screwdriver ON, press the On/Off switch. The tool will operate as long as the switch is pressed.
- To select the rotation direction (forward for tightening, reverse for loosening), slide the forward/reverse switch. The middle position locks the tool and prevents accidental activation.
LED гэрлийг ашиглах
- The front LED light automatically illuminates when the On/Off switch is pressed, providing visibility to your work area.
- The rear flashlight can be activated independently by pressing the dedicated flashlight switch located at the base of the handle. This is useful for general illumination in dark spaces.
Зураг 6.1: The integrated front LED light illuminates the work area for improved visibility during operation.
Adjusting the Rotating Handle
- To change the handle position, press the 'LOCK' button (rotating button) located near the pivot point of the handle.
- Rotate the handle to the desired position (straight or pistol grip).
- Release the 'LOCK' button to secure the handle in place.
Зураг 6.2: The rotating handle allows the screwdriver to be used in a straight or pistol grip configuration, adapting to various working conditions.
Хэрэглээний ерөнхий зөвлөмжүүд
- Always select the correct bit for the screw head to prevent stripping.
- Apply firm, steady pressure to the screwdriver to prevent cam-out.
- For delicate materials or small screws, start with a lower torque setting if available (this model has fixed torque, so apply less pressure).
Зураг 6.3: The versatile design supports multiple uses, from assembling furniture to minor household repairs.
7. Цэнэглэх
The screwdriver is equipped with a rechargeable 2.0Ah Lithium-ion battery.
- Connect the USB charging cable to the screwdriver's USB port.
- Connect the other end of the USB cable to the provided charging adapter, a computer USB port, or a power bank.
- The charging indicator light will show the charging status. Refer to the product overview diagram for its location.
- Disconnect the charger once the battery is fully charged. Avoid overcharging to prolong battery life.
Зураг 7.1: The screwdriver can be charged via USB from various sources like computers, power banks, or wall chargers.
8. Засвар үйлчилгээ
Цэвэрлэгээ
- Keep the tool's ventilation slots clean to prevent overheating.
- Багажийг зөөлөн арчиж, damp даавуу. Хүчтэй химийн бодис, зүлгүүрийн цэвэрлэгч хэрэглэж болохгүй.
Хадгалах
- Store the screwdriver and accessories in the provided storage box in a dry, cool place, away from direct sunlight and moisture.
- Хүүхдийн гар хүрэхгүй газар хадгална.
Батерейны арчилгаа
- For optimal battery life, charge the battery fully before storing for extended periods.
- Recharge the battery every 3-6 months if not in regular use.
9. Алдаа засах
If you encounter issues with your screwdriver, refer to the following table:
| Асуудал | Боломжит шалтгаан | Шийдэл |
|---|---|---|
| Халив асахгүй байна. | Батерей дуусч байна. | Батерейг бүрэн цэнэглэ. |
| Forward/reverse switch is in the neutral (locked) position. | Slide the switch to forward or reverse. | |
| Screwdriver lacks power. | Батерей бага байна. | Зайгаа цэнэглэ. |
| Битийн гулсалт эсвэл туузны эрэгний толгой. | Incorrect bit size or type. | Шурагт тохирох өрөм ашиглана уу. |
| Insufficient pressure or improper angle. | Apply firm, steady pressure and keep the bit straight. | |
| Батерейг цэнэглэхгүй байна. | Цэнэглэх кабель эсвэл адаптер буруу байна. | Try a different USB cable or adapter. Ensure connections are secure. |
Хэрэв эдгээр шийдлүүдийг туршиж үзсэний дараа асуудал хэвээр байвал хэрэглэгчийн дэмжлэгтэй холбогдоно уу.
10. Техникийн үзүүлэлтүүд
| Онцлог | Тодорхойлолт |
|---|---|
| Загварын дугаар | SD-4C |
| Ботьtage | 3.6 вольт |
| Зайны төрөл | Лити-ион |
| Зайны багтаамж | 2.0 Ах |
| Max torque | 6 Ньютон-метр (Нм) |
| Ачаалалгүй хурд | 180 эрг / мин |
| Чакны хэмжээ | 6.35 mm (1/4 inch) Hex |
| Эрчим хүчний эх үүсвэр | Батерейгаар ажилладаг |
| Бүтээгдэхүүний хэмжээ (L x W x H) | 23.2 x 19.7 x 7.1 см |
| Жин | 375 грамм |
| Материал | Металл |
11. Баталгаат хугацаа ба дэмжлэг
HYCHIKA products are manufactured to high-quality standards and are warranted against defects in materials and workmanship. For specific warranty details, including duration and coverage, please refer to the warranty card included with your purchase or visit the official HYCHIKA webсайт.
For technical assistance, troubleshooting beyond this manual, or to inquire about replacement parts, please contact HYCHIKA customer support through the contact information provided on your warranty card or the official HYCHIKA webсайт.
