BOYA BY-WM3T-U2

BOYA Dual Wireless Lavalier Microphone

Model: BY-WM3T-U2 Instruction Manual

Тохируулах, ажиллуулах, засвар үйлчилгээ хийх цогц гарын авлага.

1. Бүтээгдэхүүн дууссанview

The BOYA BY-WM3T-U2 is a dual wireless lavalier microphone system designed for use with Android phones, iPhone 15, USB Type-C smartphones, and laptops. It offers a stable audio signal transmission up to 164 feet (50 meters) and features a long battery life, superior noise reduction, and pass-through phone charging while recording. This compact and lightweight system is ideal for various recording scenarios including podcasts, YouTube videos, TikTok, live streams, vlogs, and interviews.

BOYA BY-WM3T-U2 wireless microphone system demonstrating 328ft (100m) available distance in an outdoor snowy environment.

Figure 1: The BOYA BY-WM3T-U2 offers a transmission range of up to 328 feet (100 meters) without obstructions, providing flexibility for various recording environments.

2. Хайрцагт юу багтсан бэ

All components of the BOYA BY-WM3T-U2 wireless microphone system laid out: charging case, two transmitters, one receiver, carrying pouch, two windscreens, and a USB-C charging cable.

Figure 2: Contents of the BOYA BY-WM3T-U2 package. Ensure all items are present.

Видео 1: Дууслааview of the BOYA BY-WM3T wireless microphone system components and their features.

3. Бүтээгдэхүүний бүрэлдэхүүн хэсгүүд

Detailed diagram of the BOYA BY-WM3T-RXD receiver and BY-WM3T-TX transmitter, highlighting the USB-C connector, charging contacts, USB-C charging port, built-in microphone, status indicator, NR button, and power button.

Зураг 3: Нарийвчилсан view of the receiver (BY-WM3T-RXD) and transmitter (BY-WM3T-TX) components.

4. Тохиргоо ба холболт

The BOYA BY-WM3T-U2 system is designed for ease of use with plug-and-play functionality. Follow these steps to set up your microphone system:

  1. Автомат хослуулах: For first-time use, remove the protective film from the charging contacts of the transmitters. Simply open the charging case and take out the transmitters. They will automatically pair with the receiver once the receiver is plugged into your device.
  2. Гараар асаах/унтраах: To manually turn on/off a transmitter, press and hold the power button for 2 seconds. The blue indicator light on the transmitter will illuminate when powered on and paired.
  3. Хүлээн авагчийг холбох: Plug the BY-WM3T-RXD receiver into the USB-C port of your smartphone, tablet, or laptop. The receiver's indicator light will turn solid blue once successfully paired with the transmitters.
Image demonstrating the BOYA wireless microphone receiver plugged into a smartphone, with two transmitters shown wirelessly connected, indicating plug-and-play functionality and simultaneous phone charging.

Figure 4: The receiver plugs directly into your device's USB-C port for instant connection.

Video 2: A step-by-step guide on how to use the BOYA BY-WM3T wireless lavalier microphone, covering initial setup and connection.

5. Ашиглалтын заавар

Once connected, the BOYA BY-WM3T-U2 offers intuitive controls for optimal audio capture.
