Geevon Digital Atomic Wall Clock (Model GN-228614C-T3-US) Instruction Manual

1. Танилцуулга

This manual provides detailed instructions for the setup, operation, and maintenance of your Geevon Digital Atomic Wall Clock with Moon Phase and Backlight (Model GN-228614C-T3-US). Please read this manual thoroughly before using the product to ensure proper function and longevity.

2. Юу багтсан

Савлахдаа бүх бүрэлдэхүүн хэсгүүд байгаа эсэхийг шалгана уу:

One atomic clock
One outdoor sensor
One AC/DC power adapter
Нэг хэрэглэгчийн гарын авлага

Note: 3 AAA batteries for the main unit and 2 AAA batteries for the outdoor sensor are required but not included.

3. Тохиргоо

3.1. Үндсэн нэгжийг тэжээх

The main unit can be powered by either the included AC/DC power adapter or 3 AAA batteries (not included).

Хувьсах гүйдлийн хүчийг ашиглах: Connect the AC/DC power adapter to the clock's power input port and plug it into a standard electrical outlet.
Батерей ашиглах: Open the battery compartment on the back of the clock and insert 3 new AAA batteries, observing the correct polarity (+/-).

Back of Geevon Digital Atomic Wall Clock showing battery compartment and control buttons.

Image: Back of the main clock unit with the battery compartment open, showing where to insert 3 AAA batteries. Control buttons are visible above the compartment.

Geevon Atomic Wall Clock powered by batteries, showing the battery compartment.

Image: Close-up of the back of the clock showing the battery compartment and inserted batteries. A "Low Battery Indicator" graphic is also present.

3.2. Гадна мэдрэгч суурилуулах

Утасгүй гадаа мэдрэгч нь 2 AAA батерейг шаарддаг (оруулаагүй).

Гадна мэдрэгчийн ар талд байрлах зайны тасалгааг нээнэ үү.
Insert 2 new AAA batteries, observing the correct polarity (+/-).
Зайны тасалгааг хаа.
Place the sensor in a covered outdoor location, such as under a patio or porch, to protect it from direct sunlight and rain. Ensure it is within 200 feet (60 meters) of the main unit.

Geevon Digital Atomic Wall Clock with its outdoor sensor placed on a patio table, showing the sensor's placement.

Image: The main clock unit on a table indoors and the outdoor sensor mounted on an exterior wall, illustrating the wireless connection.

Video: This video demonstrates how to install batteries in both the main clock unit and the outdoor sensor, and how the outdoor sensor transmits temperature data to the main unit. It also shows the clock's display and various features in action.

3.3. Initial Synchronization and Time Zone Setting

The clock automatically attempts to synchronize with the WWVB atomic clock signal from Fort Collins, Colorado. This process can take 2-5 days for initial synchronization, especially if the signal is weak. During signal reception, the backlight will temporarily turn off for 1-2 minutes to avoid interference.

To manually set the time zone and other settings:

Press and hold the "MODE" button for 3 seconds. The hour display will start to flash. Use the "UP" or "DOWN" buttons to set the correct hour.
Press "MODE" to confirm and move to the minute setting. Use "UP" or "DOWN" to set the correct minute.
Continue pressing "MODE" to cycle through year, month, and date settings, adjusting each with "UP" or "DOWN".
After setting the date, the Daylight Saving Time (DST) display will flash. Use "UP" or "DOWN" to turn DST on or off as applicable.
Next, the Time Zone display will flash. Use "UP" or "DOWN" to select your time zone (EST, AST, HST, AKST, PST, MST, CST).
Finally, the temperature unit (°C/°F) will flash. Use "UP" or "DOWN" to select your preferred unit.
Press "MODE" again to confirm all settings and end the setting procedures, entering the normal mode.

Geevon Digital Atomic Wall Clock displaying time and date, with an illustration of daylight saving time adjustment.

Image: The clock display showing time, date, and temperature, with graphics illustrating "Spring Forward" (+1h) and "Fall Back" (-1h) for Daylight Saving Time.

Back of Geevon Digital Atomic Wall Clock showing control buttons and a map of US time zones.

Image: Close-up of the back of the clock, highlighting the control buttons (LIGHT, MEM, 12/24, ALARM, SNZ, CH, DOWN UP/RCC, MODE) and a map of US time zones (PST, MST, CST, EST, AKST, HST, AST).

4. Ашиглалтын заавар

4.1. Дэлгэц Overview

The 8.8-inch LCD TN HD display shows the following information:

Цаг (12/24H формат)
Date and Day of the Week
Сарны үе шатууд
Indoor Temperature (°C/°F)
Outdoor Temperature (°C/°F)
Daily Minimum and Maximum Temperature Data
Temperature Trends (rising/falling)

Geevon Digital Atomic Wall Clock displaying time, date, moon phase, indoor and outdoor temperatures.

Image: The clock's large LCD display showing all its features, including time, day, date, moon phase, indoor and outdoor temperatures, and temperature trends. Dimensions of the clock are also indicated.

4.2. Арын гэрэлтүүлгийн хяналт

The clock features 3 brightness levels: Off, Dim, and Bright. The backlight behavior depends on the power source:

Хувьсах гүйдлийн хүч: The backlight can remain on continuously at your chosen brightness level.
Зайны хүч: To conserve battery life, the backlight will illuminate for 10 seconds when the top button is tapped, then turn off.

Geevon Digital Atomic Wall Clock showing three backlight levels: High, Low, and Off.

Image: The clock display shown with three different backlight settings: High, Low, and Off, demonstrating the adjustable brightness feature.

Video: This video demonstrates the three backlight brightness levels (Off, Dim, Bright) of the Geevon Atomic Wall Clock and how to adjust them by touching the top button. It also shows the clock in various room settings.

4.3. Сэрүүлэг болон түр хойшлуулах функц

The clock includes an alarm with a snooze feature:

Сэрүүлгийг тохируулах: Press the "ALARM" button on the back of the clock to enter alarm setting mode. Use "UP" or "DOWN" to set the desired alarm time. Press "ALARM" again to confirm.
Activating Alarm: Once set, the alarm will sound with a gradually increasing "beep" sound.
Түр хойшлуулах: Press the "SNZ" button (top button) during the alarm to activate the 5-minute snooze function.
Сэрүүлгийг зогсоох: To stop the alarm completely, press any other button besides "SNZ". If no action is taken, the alarm will automatically stop after 2 minutes.

Geevon Digital Atomic Wall Clock with alarm and snooze icons, showing a person waking up.

Image: The clock display with icons for "Ascending Beep" and "5-minute Snooze", illustrating the alarm features. A person is shown waking up in bed.

4.4. Температурын нэгжийг солих

To switch between Celsius (°C) and Fahrenheit (°F) for temperature display, press the "UP/RCC" button on the back of the clock during normal operation.

4.5. Max/Min Temperature Records

The clock records the daily minimum and maximum indoor and outdoor temperatures. Press the "MEM" button on the back of the clock to view these records. Press it again to cycle through current, maximum, and minimum readings.

5. Байршуулах сонголтууд

The Geevon Digital Atomic Wall Clock offers versatile placement options:

Ширээний хэрэглээ: Utilize the integrated tripod stand on the back for stable placement on a desk, nightstand, or shelf.
Хананд суурилуулах: Use the two hanging holes on the back to mount the clock securely on a wall.

Geevon Digital Atomic Wall Clock showing both tabletop stand and wall hanging options.

Image: The clock is shown with its foldable stand for tabletop use and also with hanging holes for wall mounting, illustrating its two placement methods.

For optimal performance, place both the main unit and the outdoor sensor at least 3 feet (1 meter) away from electronic devices such as TVs, computers, microwaves, or radios, as these can cause electromagnetic interference.

6. Засвар үйлчилгээ

Цэвэрлэгээ: Wipe the clock and sensor with a soft, dry cloth. Do not use abrasive cleaners or solvents.
Зай солих: Replace batteries in both the main unit and outdoor sensor when the low battery indicator appears on the display. Always replace all batteries at the same time with new ones.
Хадгалах: If storing the unit for an extended period, remove all batteries to prevent leakage.

7. Алдаа засах

Асуудал	Боломжит шалтгаан	Шийдэл
Үндсэн төхөөрөмж дээр дэлгэц байхгүй.	Цахилгаангүй эсвэл цэнэггүй батерей байхгүй.	Ensure AC adapter is properly connected or replace batteries.
Гаднах температурыг харуулахгүй эсвэл буруу байна.	Outdoor sensor batteries dead, out of range, or interference.	Replace sensor batteries. Move sensor closer to the main unit. Ensure no large metal objects or electronics are between units.
Атомын цаг синхрончлогдохгүй байна.	Weak WWVB signal, interference, or incorrect time zone.	Ensure correct time zone is set. Move clock to a location with better signal reception (e.g., near a window, away from electronics). Allow 2-5 days for initial synchronization. Signal reception is usually better at night.
Backlight not staying on (when using AC power).	Цахилгаан адаптер холбогдоогүй эсвэл алдаатай байна.	Ensure AC adapter is securely plugged in. If problem persists, contact support.

8. Техникийн үзүүлэлтүүд

Загварын дугаар: GN-228614C-T3-US
Брэнд: Геевон
Дэлгэцийн төрөл: Digital LCD TN HD
Дэлгэцийн хэмжээ: 8.8 инч
Цахилгаан эх үүсвэр (Үндсэн нэгж): AC/DC Power Adapter (included) or 3 x AAA Batteries (not included)
Цахилгаан эх үүсвэр (Гадна мэдрэгч): 2 x AAA батерей (оруулаагүй)
Холболт: Утасгүй (гадаа мэдрэгчтэй)
Гаднах мэдрэгчийн хүрээ: Ил задгай талбайд 200 фут (60 м) хүртэл
Температурын нарийвчлал: ±1 °C
Онцлог шинж чанарууд: Atomic Clock (WWVB), Moon Phase, Backlight (3 levels), Alarm with Snooze, Indoor/Outdoor Temperature, Max/Min Temperature Records, Temperature Trend Indicator, 12/24H Time Format, Calendar (Day, Month, Date, Day of Week), Daylight Saving Time (DST) On/Off.
Материал: Акрилонитрил бутадиен стирол (ABS)
Бүтээгдэхүүний хэмжээ: 2.1"D x 7.87"W x 7.75"H
Барааны жин: 1.4 фунт

9. Баталгаат хугацаа ба дэмжлэг

Geevon is committed to providing high-quality products and excellent customer service. If you encounter any issues or have questions regarding your Geevon Digital Atomic Wall Clock, please contact our customer support team. We offer lifetime consulting services and are available 24/7 online.

Дэмжлэг авахыг хүсвэл худалдан авалттайгаа хамт өгсөн холбоо барих мэдээллийг лавлах эсвэл Geevon-ы албан ёсны вэбсайтад зочилно уу. webсайт.
