1. Танилцуулга
This manual provides detailed instructions for the VIKYLIN 8MP Fixed Dome PoE IP Camera Outdoor, Model VK-YC2583I-28. This camera features 4K Ultra HD resolution, full-color night vision, human/vehicle detection, a built-in microphone, and Power over Ethernet (PoE) for simplified installation. Please read this manual thoroughly before installation and operation to ensure proper use and optimal performance.
2. Багцын агуулга
Доор жагсаасан бүх зүйл таны багцад байгаа эсэхийг шалгаарай. Хэрэв ямар нэгэн зүйл дутуу эсвэл эвдэрсэн бол хэрэглэгчийн дэмжлэгтэй холбоо барина уу.
- 1x 4K PoE IP Dome Camera
- 1x Base Sticker
- 1x зааварчилгааны гарын авлага
- 1x Screw Bag (containing screws for mounting)
- 1x Waterproof Kit
Image: Package contents of the VIKYLIN 8MP Fixed Dome PoE IP Camera.
3. Бүтээгдэхүүний онцлог
- 4K Ultra HD нягтрал: Provides clear image quality with 8MP (3840 × 2160) resolution at 20 frames per second, featuring a 1/2.8” 8 Megapixel Scan CMOS sensor and a 2.8mm fixed lens for a 112° ultra-wide viewөнцөг.
- Бүрэн өнгөт шөнийн хараа: Equipped with F1.6 aperture and soft supplemental lighting, this camera provides detailed full-color video even in extremely dark scenes.
- Ухаалаг хос гэрэл: The camera intelligently switches between IR (infrared) and warm light illumination based on detection, ensuring optimal night vision while deterring intruders with a warm light flash.
- Human/Vehicle Detection: Advanced detection functions reduce false alarms by accurately identifying human and vehicle movement. Detection areas and sensitivity can be adjusted.
- Суурилагдсан микрофон: Capture clear audio from the camera's vicinity, allowing for one-way audio monitoring and recording.
- Ethernet дээрх хүч (PoE): Simplifies installation by providing both power and data connection through a single Cat 5 or Cat 6 Ethernet cable.
- Бат бөх дизайн: IP67 weatherproof and IK10 vandal-proof rating ensures reliable outdoor performance in various conditions.
- Үр дүнтэй шахалт: Utilizes H.265+/H.264 encoding technology to save bandwidth and storage space without compromising video quality.
Feature Demonstrations
Video: Demonstration of the camera's UltraHD 4K picture display quality.
Image: Smart Dual Illuminators in action, providing full-color night vision when a target is detected.
Image: Human and Vehicle Detection capabilities, highlighting reduced false alarms.
Video: Full Color Camera Night Vision demonstration, showcasing clear imaging in low-light conditions.
Image: Built-in microphone feature allowing for one-way audio communication.
4. Тохиргоо ба суурилуулалт
The VIKYLIN 8MP Fixed Dome PoE IP Camera is designed for easy installation using Power over Ethernet (PoE). A single Ethernet cable provides both power and data connectivity.
4.1 Физик суурилуулалт
- Байршлыг сонгох: Select a suitable indoor or outdoor location for mounting. The camera is IP67 rated for weather resistance and IK10 for vandal resistance.
- Суурилуулалт: Use the provided base sticker as a template to mark drill holes. Secure the camera using the included screws.
- Кабелийн холболт: Connect a Cat 5 or Cat 6 Ethernet cable from the camera to a PoE injector, PoE switch, or PoE NVR. Ensure the waterproof kit is properly installed for outdoor use.
Image: Camera's IP67 weatherproof and IK10 vandal-proof design.
4.2 Анхны тохиргоо
After physical installation, configure the camera using the web интерфэйс эсвэл гар утасны програм.
- Сүлжээнд холбогдох: Ensure the camera is connected to your network via PoE.
- Камерыг нээх: Use a PC software like VMS or SADP Tool to search for the camera device on your network.
- Хандалт Web Интерфэйс: Нээлттэй a web browser and enter the camera's IP address. Log in using the default credentials (usually admin/admin or admin/12345).
- Enable P2P: Navigate to Configuration > Network > P2P and enable the P2P function. Scan the QR code to add the device to your mobile app.
Video: Detailed guide on configuring the 4K Full Color PoE IP Dome Camera, including human/vehicle detection settings and night vision options.
5. Ашиглалтын заавар
Operate your VIKYLIN IP camera using the 'Remoteeyes' mobile app or compatible PC software.
5.1 Mobile App (Remoteeyes)
- Апп татаж авах: Download the 'Remoteeyes' app from the Apple App Store or Google Play Store.
- Төхөөрөмж нэмэх: Use the P2P function (QR code scan) to add your camera to the app.
- Амьд View: Access live video feeds from your camera anytime, anywhere.
- Тоглуулах: Review foo бүртгэгдсэнtage with smart playback features.
- Нэг талын аудио: Utilize the built-in microphone for one-way audio communication.
- Анхааруулга: Receive real-time video/snapshot alerts on your mobile phone when human or vehicle detection is triggered.
Image: Real-time alerts and deterrent features in action.
5.2 PC Software and Third-Party Compatibility
The camera is compatible with free PC software (VMS) and third-party monitoring software such as Blue Iris, iSpy, and VLC. It supports the Open Network Video Interface protocol (ONVIF) and RTSP for integration with various systems.
Local PC/NVR/NAS video storage is supported, with options for 24/7 recording or motion-triggered video to NVR or FTP.
6. Засвар үйлчилгээ
To ensure optimal performance and longevity of your VIKYLIN IP Camera, consider the following maintenance tips:
- Тогтмол цэвэрлэгээ: Камерын линз болон орон сууцыг үе үе зөөлөн, damp тоос шороо, хог хаягдлыг арилгах даавуу. Зүлгүүрийн цэвэрлэгчээс зайлсхий.
- Програм хангамжийн шинэчлэлтүүд: Үйлдвэрлэгчийг шалгана уу website or app for available firmware updates to ensure your camera has the latest features and security enhancements.
- Кабелийн үзлэг: Regularly inspect the Ethernet cable and connections for any signs of wear or damage, especially for outdoor installations.
- Хадгалах менежмент: If using local storage (Micro SD card, NVR, NAS), ensure sufficient storage space is available and manage recordings as needed.
7. Алдаа засах
If you encounter issues with your VIKYLIN 8MP Fixed Dome PoE IP Camera, refer to the following common troubleshooting steps:
- Цахилгаан/холболт байхгүй:
- Verify the Ethernet cable is securely connected to both the camera and the PoE source (NVR, switch, or injector).
- Ensure the PoE source is powered on and functioning correctly.
- Кабель гэмтсэн эсэхийг шалгана уу.
- Cannot Access Camera:
- Confirm the camera's IP address using the SADP Tool or VMS software.
- Ensure your computer or mobile device is on the same network as the camera.
- Check firewall settings on your computer or router that might be blocking access.
- Reset the camera to factory defaults if you have forgotten the password (a reset button is available on the camera).
- Зургийн чанар муу:
- Камерын линзийг цэвэрлэ.
- Check network bandwidth; insufficient bandwidth can affect streaming quality.
- Adjust image settings (brightness, contrast, WDR) in the camera's web интерфэйс эсвэл апп.
- Хуурамч дохиолол:
- Adjust the sensitivity of human/vehicle detection.
- Define specific detection zones to exclude areas with irrelevant motion (e.g., trees swaying).
For further assistance, please contact VIKYLIN customer support.
8. Техникийн үзүүлэлтүүд
| Онцлог | Дэлгэрэнгүй |
|---|---|
| Загварын нэр | 4K Dual-light Built-in Microphone PoE IP Dome Camera (VK-YC2583I-28-N) |
| Загварын дугаар | VK-YC2583I-28 |
| Үр дүнтэй шийдэл | 8 MP (3840 x 2160) |
| Frame Rate | Секундэд 20 кадр |
| Линз | 2.8mm fixed lens, F1.6 Super Aperture |
| Viewing өнцөг | 112° хэт өргөн |
| Шөнийн харааны хүрээ | 98 Feet (Full Color / IR View) |
| Гэрэл багатай технологи | Night Color / IR, Smart Dual Light |
| Аудио | Built-in Mic (One-way Audio) |
| Илрүүлэх | Хүн/Тээврийн хэрэгсэл илрүүлэх |
| Холболтын технологи | Ethernet (PoE) |
| Эрчим хүчний эх үүсвэр | Утастай Цахилгаан (PoE) |
| Хадгалах | Local PC/NVR/NAS Video Storage, supports up to 256GB Micro SD card (not included) |
| Тохиромжтой байдал | PoE NVR, ONVIF, Blue Iris, iSpy, VLC, Remoteeyes App (iOS/Android), VMS PC software |
| Олон улсын хамгаалалтын зэрэглэл | IP67 (Ус нэвтэрдэггүй) |
| Нөлөөллийн хамгаалалт | IK10 (Vandal-proof) |
| Ашиглалтын температур | -30°C - 60°C (-22°F - 140°F) |
| Чийгшил | < 90% |
| Материал | Металл |
| Бүтээгдэхүүний хэмжээс | 5.51 x 5.51 x 3.94 инч |
| Зүйлийн жин | 1.17 фунт |
Image: Technical specifications overview камерын.
9. Баталгаат хугацаа ба дэмжлэг
VIKYLIN provides comprehensive support for its products.
- Баталгаат хугацаа: The product includes a 2-year warranty.
- Техникийн дэмжлэг: Насан туршийн техникийн дэмжлэг авах боломжтой.
- Холбоо барих мэдээлэл: For any questions or issues, please contact our support team via email at cairo@vikylin.com.
- Хамгаалалтын төлөвлөгөө: Extended protection plans are available for purchase separately (e.g., 2-Year Protection Plan, 3-Year Protection Plan, Complete Protect).
