1. Танилцуулга
The ANENG DM3004A is a high-accuracy handheld metal detector designed for quickly locating small metallic objects. It is suitable for various applications, including security checks, finding lost items, and educational purposes. This manual provides essential information for the safe and effective use of your device, covering setup, operation, maintenance, and troubleshooting.
2. Аюулгүй байдлын мэдээлэл
- Төхөөрөмжийг ажиллуулахын өмнө бүх зааврыг уншина уу.
- Төхөөрөмжийг хэт өндөр температур, чийгшил эсвэл нарны шууд тусгалд бүү байлга.
- Ensure correct battery polarity when installing batteries.
- Хэрэв төхөөрөмжийг удаан хугацаагаар ашиглахгүй бол ус гоожихоос сэргийлж зайгаа салга.
- Төхөөрөмжийг хүчтэй соронзон орноос хол байлга.
- This device is not a toy; keep out of reach of children.
3. Багцын агуулга
Хүлээн авахдаа багцын агуулгыг шалгана уу. Хэрэв ямар нэгэн зүйл алга болсон эсвэл гэмтсэн бол хэрэглэгчийн дэмжлэгтэй холбогдоно уу.
- 1 x ANENG DM3004A Handheld Metal Detector
- 1 х хэрэглэгчийн гарын авлага
Figure 3.1: ANENG DM3004A Metal Detector with its retail packaging and included user manual.
4. Бүтээгдэхүүн дууссанview
Familiarize yourself with the components of your ANENG DM3004A metal detector.
- Detection Coil: The circular part responsible for detecting metallic objects.
- Бариул: Эргономикийн хувьд тав тухтай атгахад зориулагдсан.
- Эрчим хүч солих: Toggles the device ON/OFF.
- Буззер: Emits an audible alarm when metal is detected.
- LED үзүүлэлт: Lights up to visually indicate metal detection.
- Зайны тасалгаа: Located at the base of the handle for battery installation.
Figure 4.1: Detail of the ON/OFF switch and the buzzer alarm area on the ANENG DM3004A.
Figure 4.2: The red LED indicator illuminates upon metal detection. The probe head can be rotated up to 180 degrees for versatile use.
5. Тохиргоо
5.1 Батерей суурилуулах
- Locate the battery compartment cover at the bottom of the handle.
- Тасалгааг нээхийн тулд тагийг нь гулсуулж эсвэл тайл.
- Insert one DC9V 6F22 battery, ensuring correct polarity (+ and - terminals match the markings inside the compartment).
- Зайны тасалгааны тагийг сайтар хаа.
Жич: The battery is not included in the package and must be purchased separately.
6. Ашиглалтын заавар
6.1 Асаах/унтраах
- To turn on the device, slide the power switch to the "ON" position. The device will emit a short beep, indicating it is ready for use.
- To turn off the device, slide the power switch to the "OFF" position.
6.2 Металл илрүүлэлт
- Hold the metal detector by the handle, keeping the detection coil away from your body and other metallic objects.
- Slowly sweep the detection coil over the area you wish to scan. Maintain a consistent distance from the surface.
- When a metallic object is detected, the device will emit an audible alarm (buzzer) and the red LED indicator will light up. The intensity of the alarm and light may increase as you get closer to the object.
- Pinpoint the exact location by moving the coil slowly in a cross-pattern over the detected area.
Зураг 6.1: Жишээ ньample of using the ANENG DM3004A for security scanning.
6.3 Detection Distances
The detection distance varies depending on the size, shape, and composition of the metallic object.
- Small nails: 0-6 cm (0-2.36 inches)
- Lighters, cigarettes, chewing gum, dry batteries: 0-8 cm (0-3.15 inches)
- Lithium batteries, mobile phones: 0-12 cm (0-4.72 inches)
- Weapon tools (e.g., knives, guns): 0-15 cm (0-5.90 inches)
Figure 6.2: Approximate detection distances for common metallic objects.
6.4 Applicable Environments
The ANENG DM3004A is suitable for use in various environments where metal detection is required.
- High-speed rail stations
- Нисэх буудлууд
- Метронууд
- Эмнэлгүүд
- Event venues
- Sports meetings
Зураг 6.3: Жишээ ньamples of suitable environments for the ANENG DM3004A metal detector.
7. Засвар үйлчилгээ
- Цэвэрлэгээ: Төхөөрөмжийг зөөлөн, хуурай даавуугаар арчина. Зүлгүүрийн цэвэрлэгч, уусгагчийг бүү ашигла.
- Зай солих: Replace the 9V battery when the detection performance decreases or the device fails to power on.
- Хадгалах: Store the metal detector in a cool, dry place when not in use. Remove the battery if storing for extended periods.
- Нөлөөлөлөөс зайлсхийх: Protect the device from drops and strong impacts.
8. Алдаа засах
| Асуудал | Боломжит шалтгаан | Шийдэл |
|---|---|---|
| Төхөөрөмж асахгүй байна. | Батерей дууссан эсвэл буруу суурилуулсан. | Батерейны туйлшралыг шалгаад шинэ 9V батерейгаар солино уу. |
| No alarm or LED indication when metal is present. | Battery low; object too small or too far; device malfunction. | Replace battery; ensure object is within detection range; contact customer support if issue persists. |
| False alarms or continuous beeping. | Interference from other electronic devices or large metallic structures nearby. | Move away from sources of interference; ensure no metal is near the coil during startup. |
9. Техникийн үзүүлэлтүүд
| Онцлог | Дэлгэрэнгүй |
|---|---|
| Загвар | DM3004A |
| Зайны төрөл | DC9V 6F22 (Not Included) |
| Ашиглалтын температур | -10℃ ~ 50℃ (14°F ~ 122°F) |
| Одоогийн хэрэглээ | <3мА |
| Зүйлийн жин | 244 г (батерейгүй) |
| Product Dimensions (Stretch) | Approx. 394x140mm (15.51x5.51 inch) |
| Search Head Diameter | 140 мм |
| Хэмжилтийн нарийвчлал | 90% |
| Гарал үүслийн улс | Хятад |
10. Баталгаат хугацаа ба дэмжлэг
10.1 Баталгаат хугацааны мэдээлэл
This product comes with a standard manufacturer's warranty against defects in materials and workmanship. The specific terms and duration of the warranty may vary by region and retailer. Please retain your proof of purchase for warranty claims. The warranty does not cover damage caused by misuse, accidents, unauthorized modifications, or normal wear and tear.
10.2 Хэрэглэгчийн дэмжлэг
If you encounter any issues or have questions regarding your ANENG DM3004A metal detector that are not covered in this manual, please contact the retailer or the manufacturer's customer service for assistance. Provide your product model number and a detailed description of the issue when seeking support.
