1. Танилцуулга
This manual provides detailed instructions for the installation, operation, and maintenance of your WUPRO 133-inch Electric Projector Ceiling Recessed Screen. Designed for optimal viewing, this screen features a gray fabric with a 0.9 gain, supporting 4K/8K HD projection and offering a wide 160° viewing angle. Please read this manual thoroughly before use to ensure proper setup and performance.
Image: The WUPRO Electric Projector Screen seamlessly integrated into a home theater environment.
2. Аюулгүй байдлын мэдээлэл
Бүтээгдэхүүнийг гэмтээх, гэмтээхгүйн тулд дараах аюулгүй байдлын арга хэмжээг үргэлж дагаж мөрдөөрэй.
- Дэлгэцийг орон нутгийн цахилгаан болон барилгын бүх дүрмийг дагаж мөрдөж, мэргэшсэн ажилтнууд суурилуулсан эсэхийг шалгаарай.
- Do not attempt to disassemble or modify the screen. This may void the warranty and pose a safety risk.
- Keep hands and objects clear of the screen's path during operation to prevent pinching or damage.
- Засвар, цэвэрлэгээ хийхээс өмнө цахилгааныг салга.
- Do not expose the screen to excessive moisture or extreme temperatures.
3. Багцын агуулга
Суулгацыг үргэлжлүүлэхийн өмнө бүх бүрэлдэхүүн хэсгүүд байгаа эсэхийг шалгана уу:
- WUPRO Electric Projector Screen Unit
- Алсын удирдлага
- Суурилуулах тоног төхөөрөмж (эрэг, зангуу, хаалт)
- Цахилгаан кабель
- Хэрэглэгчийн гарын авлага (энэ баримт бичиг)
4. Тохиргоо
4.1 Суурилуулалтын өмнөх шалгалт
Суулгахын өмнө болгоомжтой дахин хийнэ үүview the screen's technical specifications to ensure compatibility with your projector and installation environment. If you have any questions, consult the manufacturer.
4.2 Суурилуулах сонголтууд
The WUPRO Electric Projector Screen supports both wall and ceiling mounting. Choose the option that best suits your room layout and projector placement.
Image: Illustration of available wall and ceiling mounting configurations.
4.3 Суурилуулалтын үе шатууд
The screen requires manual installation. Follow these general steps:
- Хэмжих ба тэмдэглэх: Determine the optimal screen position. Mark the drilling points for the mounting brackets on the wall or ceiling, ensuring they are level and correctly spaced according to the screen's dimensions.
- Өрөмдлөгийн цооног: Use an appropriate drill bit to create holes at the marked positions. Insert wall anchors if necessary.
- Хаалт хавсаргах: Securely fasten the mounting brackets to the wall or ceiling using the provided screws.
- Mount Screen: Carefully lift the screen unit and attach it to the installed brackets. Ensure it is securely locked in place.
- Эрчим хүчийг холбох: Plug the power cable into the screen unit and then into a suitable power outlet.
Refer to the detailed diagram for selecting the appropriate screen size for your space:
Image: Visual guide for selecting the appropriate screen size for your room.
5. Ашиглалтын заавар
5.1 Хяналтын сонголтууд
Your WUPRO projector screen offers multiple control methods for maximum convenience:
- Алсын удирдлага: Use the included wireless remote to extend or retract the screen.
- Утастай удирдлага: Connect a wired switch (if available and installed) for direct control.
- Projector Sync: The screen can synchronize with your projector, automatically deploying when the projector is turned on and retracting when it's turned off.
Зураг: Дууслааview of the multiple control options for the projector screen.
5.2 Дэлгэцийн ажиллагаа
To extend the screen, press the 'DOWN' button on the remote control or wired switch. To retract, press the 'UP' button. The screen will stop automatically at its fully extended or retracted position. You can also pause the screen at any desired height by pressing the 'STOP' button.
5.3 ViewТуршлага
The gray fabric screen with 0.9 gain is optimized for environments with low to moderate ambient light, providing enhanced contrast and color saturation. The 160° viewing angle ensures a clear and vibrant picture from various positions within the room.
Image: Visual representation of the screen's wide 160° viewөнцөг.
Image: Details of the screen fabric, showcasing balanced colors, low speckle, and 0.9 gain.
6. Засвар үйлчилгээ
6.1 Cleaning the Screen Surface
To clean the screen surface, gently wipe it with a soft, damp cloth using mild soap and water. Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the screen material. Allow the screen to air dry completely before retracting.
6.2 Ерөнхий арчилгаа
- Avoid touching the screen surface with bare hands to prevent fingerprints and smudges.
- Ensure the screen is fully retracted when not in use to protect it from dust and damage.
- Regularly check mounting hardware for tightness and security.
7. Алдаа засах
If you encounter issues with your WUPRO projector screen, refer to the following common problems and solutions:
| Асуудал | Боломжит шалтгаан | Шийдэл |
|---|---|---|
| Screen does not extend/retract. | No power; Remote control battery low; Motor malfunction. | Check power connection; Replace remote batteries; Contact support. |
| Screen stops midway. | Obstruction; Limit switch setting. | Саад бэрхшээлийг арилгах; Хязгаарлалтын унтраалгын тохируулгын талаар гарын авлагаас лавлана уу (хэрэв байгаа бол). |
| Зураг гажуудсан эсвэл долгионтой харагдаж байна. | Screen not flat; Projector misalignment. | Ensure screen is fully extended and tensioned; Adjust projector position. |
8. Техникийн үзүүлэлтүүд
Key technical specifications for the WUPRO 133-inch Electric Projector Ceiling Recessed Screen:
| Онцлог | Дэлгэрэнгүй |
|---|---|
| Брэнд | WUPRO |
| Загвар | 133" Electric Projector Ceiling Recessed Screen |
| Бүтээгдэхүүний хэмжээс | 0.01 x 124 x 220 cm (approximate housing) |
| Хэмжээ харуулах | 115.9" x 65.19" |
| Харьцаа | 16:9 |
| Viewing өнцөг | 160 градус |
| Дэлгэцийн гадаргуугийн тодорхойлолт | Matte Grey Fabric |
| Олз | 0.9 |
| Суурилуулалтын төрөл | Таазны бэхэлгээ, хананд бэхэлгээ |
For detailed dimensions and weight across different sizes, please refer to the parameters table:
Image: Detailed parameters table for various screen sizes.
9. Баталгаат хугацаа ба дэмжлэг
9.1 Price Protection
WUPRO offers a 30-day price protection. If the price of your WUPRO screen drops within 30 days of purchase on Amazon, you may be eligible for a refund of the difference. To claim, purchase a WUPRO series screen on Amazon, find a lower price within 30 days, take a screenshot, and contact WUPRO support.
9.2 Хэрэглэгчийн дэмжлэг
For technical assistance, warranty claims, or any other inquiries, please contact WUPRO customer support:
- WhatsApp: +86 15892099803
- Refer to your Amazon order details for additional support information.
