GAMEMAX N90 BG ATX PC Case User Manual

1. Танилцуулга

This manual provides detailed instructions for the installation, operation, and maintenance of your GAMEMAX N90 BG ATX PC Case. The N90 BG features a modular dual-chamber design, a 512-LED matrix display, and panoramic curved glass. It is designed for BTF motherboards, offering a cable-free interior, efficient 270° cooling, and includes six ARGB PWM fans. Please read this manual thoroughly before beginning assembly to ensure proper setup and optimal performance.

Зураг 1: Урд тал view of the GAMEMAX N90 BG ATX PC Case, showcasing its panoramic curved glass, internal components, and the integrated LED display.

2. Багцын агуулга

Verify that all components are present before proceeding with the installation:

• GAMEMAX N90 BG ATX PC Case
• Дагалдах хэрэгсэл (эрэг, тулгуур, кабель зангиа)
• Six pre-installed ARGB PWM fans
• Хэрэглэгчийн гарын авлага (энэ баримт бичиг)

3. Тохиргоо ба суурилуулалт

Follow these steps for proper assembly of your PC components within the GAMEMAX N90 BG case.

3.1. Кейс бэлтгэх

1. Савлах: Хайрцгийг савлагаанаас нь болгоомжтой салга.
2. Самбарыг арилгах: The panoramic curved glass and side panels can be removed for easier access. Refer to Figure 2 for an interior view.

Зураг 2: Дотоод засал view of the GAMEMAX N90 BG case, highlighting the spacious motherboard tray and fan mounting locations.

Зураг 3: Хажуу тал view of the case with the panel removed, providing access to the internal structure for component installation.

3.2. Эх хавтанг суурилуулах

The N90 BG supports ATX motherboards, including BTF (Back-To-the-Future) motherboards for a cable-free aesthetic. Install the necessary standoffs for your motherboard size, then carefully place the motherboard and secure it with screws.

Зураг 4: Дотоод view demonstrating potential component placement and cable routing paths.

3.3. Цахилгаан хангамжийн суурилуулалт

The case features a bottom mount for the power supply. Install your power supply unit (PSU) into the designated compartment at the bottom of the case and secure it with screws from the rear.

Зураг 5: Ар талд view of the case, illustrating the power supply mounting area and expansion slots.

3.4. Хадгалах диск суурилуулах

Utilize the available drive bays for 2.5-inch SSDs or 3.5-inch HDDs. Refer to the accessory box for specific mounting hardware.

3.5. Сэнс болон Радиатор суурилуулах

The case comes with six pre-installed ARGB PWM fans for efficient 270° cooling. Additional fans or radiators can be mounted in various positions (top, side, rear) as needed. Ensure proper airflow direction for optimal cooling.

Figure 6: Top-down interior view, showing available mounting points for additional fans or liquid cooling radiators.

3.6. Кабелийн менежмент

The dual-chamber design and BTF motherboard compatibility facilitate excellent cable management, allowing for a clean, cable-free interior. Route all cables through the designated cutouts and secure them using the provided cable ties in the rear chamber.

Зураг 7: Хажуу тал view of the case, illustrating the solid panel that conceals the cable management area.

4. Ашиглалтын заавар

4.1. Асаах

After all components are installed and cables are connected, close all panels. Connect the power cable to your PSU and press the power button located on the front panel of the case.

4.2. 512-LED Matrix Display

The integrated 512-LED matrix display on the front panel can be customized to show various information or patterns. Refer to your motherboard's software or the GAMEMAX utility (if applicable) for configuration options.

4.3. ARGB PWM Fans

The six pre-installed ARGB PWM fans are connected to a controller or directly to your motherboard. Fan speed and RGB lighting can typically be controlled via motherboard software (e.g., ASUS Aura Sync, MSI Mystic Light, Gigabyte RGB Fusion) or a dedicated fan controller.

5. Засвар үйлчилгээ

Тогтмол засвар үйлчилгээ нь таны компьютерын урт наслалт, оновчтой ажиллагааг баталгаажуулдаг.

• Тоосны шүүлтүүр: Periodically clean the dust filters located on the intake areas of the case. Gently remove them and clean with compressed air or water (ensure they are completely dry before reinstallation).
• Гадна цэвэрлэгээ: Wipe the exterior surfaces, including the panoramic curved glass, with a soft, damp даавуу. Зүлгүүрийн цэвэрлэгчээс зайлсхий.
• Дотоод цэвэрлэгээ: Use compressed air to remove dust from internal components and fans. Ensure the system is powered off and unplugged before cleaning.

6. Алдаа засах

Хэрэв танд асуудал тулгарвал дараах нийтлэг алдааг олж засварлах алхмуудыг үзнэ үү.

• Эрчим хүчгүй:
  • Цахилгаан тэжээлийн хангамжийг асааж, ханын залгуурт зөв холбосон эсэхийг шалгана уу.
  • Бүх цахилгааны кабель (24 зүүтэй ATX, CPU, GPU) эх хавтан болон эд ангиудад найдвартай холбогдсон эсэхийг шалгана уу.
  • Урд талын самбарын цахилгаан унтраалгын эх хавтантай холболтыг шалгана уу.
• Fans Not Spinning / LEDs Not Lighting Up:
  • Confirm fan and ARGB cables are correctly connected to the motherboard headers or fan controller.
  • Check motherboard BIOS/UEFI settings or software for fan and RGB control.
• Дэлгэцийн асуудлууд:
  • Ensure your monitor is connected to the graphics card, not the motherboard's integrated graphics (unless using integrated graphics).
  • График карт нь PCIe үүрэндээ зөв суурилагдсан бөгөөд хангалттай цэнэгтэй эсэхийг шалгаарай.

For further assistance, consult your motherboard manual or the GAMEMAX support resources.

7. Техникийн үзүүлэлтүүд

8. Баталгаат хугацаа ба дэмжлэг

GAMEMAX stands behind the quality of its products. While specific warranty details may vary by region, GAMEMAX products are designed for reliability and performance.

For technical support, warranty claims, or further inquiries, please visit the official GAMEMAX store or contact their customer service. You can find more information and support resources at the Амазон дээрх GAMEMAX дэлгүүр.
