Аюулгүй байдлын чухал мэдээлэл
Please read this entire instruction manual carefully before installing or using your Stelpro Ultra-Quiet Wall Convector Heater. Failure to follow these instructions may result in fire, electric shock, serious injury, or property damage. Keep this manual for future reference.
- Энэ халаагуур нь зориулагдсан hardwired installation only. It is not a plug-in unit.
- Энэ халаагуур does not include a built-in thermostat. An external electronic wall thermostat (sold separately) is required for operation and temperature control. Mechanical thermostats are not compatible.
- Ensure the electrical supply matches the heater's requirements (240V or 208V).
- Суурилуулалтыг бүх улсын болон орон нутгийн цахилгааны дүрмийн дагуу мэргэшсэн цахилгаанчин гүйцэтгэнэ.
- Do not install the heater near flammable materials or in areas where gasoline, paint, or other flammable liquids are stored or used.
- Maintain proper clearances from walls, furniture, and drapes as specified in the installation guide.

Тохиргоо ба суурилуулалт
The Stelpro ASHC1502WCW convector heater is designed for surface-mount wall installation. For safe and proper operation, professional installation is highly recommended.
Суурилуулалт
The heater features a concealed mounting bracket and a back entry plate with cable clamps for a clean, secure installation. Ensure the mounting surface is flat and capable of supporting the heater's weight.

Цахилгаан холболт
This unit requires a 240V or 208V hardwired electrical connection. It is crucial to connect the heater to a dedicated circuit with appropriate overcurrent protection. Refer to the wiring diagram provided with the product packaging for detailed electrical connection instructions.

Thermostat Requirement
As this heater does not have an integrated thermostat, an external electronic wall thermostat must be installed and wired to control the heater's operation. Ensure the chosen thermostat is compatible with 240V/208V electric heating systems.
Ашиглалтын заавар
Once properly installed and connected to an electronic wall thermostat, operating your Stelpro convector heater is straightforward.
- Асаах: Ensure the circuit breaker supplying power to the heater is in the 'ON' position.
- Термостатыг тохируулах: Use your external electronic wall thermostat to set the desired room temperature. The heater will activate when the room temperature falls below the set point and deactivate once the set point is reached.
- Чимээгүй ажиллагаа: This convector heater operates silently, providing consistent warmth without fan noise.
- Анхны хэрэглээ: During the first few hours of operation, a slight odor may be emitted. This is normal and will dissipate quickly as manufacturing residues burn off. Ensure adequate ventilation during this period.

Засвар үйлчилгээ
Your Stelpro convector heater requires minimal maintenance to ensure optimal performance and longevity.
- Цэвэрлэгээ: Халаагчийн гадна талыг зөөлөн, d аргаар үе үе цэвэрлэж байгаарайamp cloth. Do not use abrasive cleaners or solvents. Ensure the heater is turned off and cool before cleaning.
- Тоос арилгах: Use a vacuum cleaner with a brush attachment to remove dust from the air intake and discharge grilles. This helps maintain efficient airflow.
- Шалгалт: Annually, inspect the heater for any signs of damage or loose connections. If any issues are found, contact a qualified electrician for inspection and repair.
- Саад болохгүй: Never block the air intake or discharge openings of the heater. This can lead to overheating and reduced efficiency.
Алдааг олж засварлах
If your Stelpro convector heater is not operating as expected, consult the following troubleshooting guide before contacting support.
| Асуудал | Боломжит шалтгаан | Шийдэл |
|---|---|---|
| Халаагч асахгүй байна. | Цахилгаан хангамж байхгүй. Термостатыг хэт бага тохируулсан. Faulty wiring or thermostat. | Хэлхээ таслагчийг шалгана уу. Термостатын тохиргоог нэмэгдүүлэх. Мэргэшсэн цахилгаанчинтай зөвлөлдөх. |
| Халаагч нь хангалтгүй дулаан үүсгэдэг. | Room size exceeds heating capacity. Airflow obstructed. Thermostat calibration issue. | Ensure heater matches room size (up to 150 sq ft). Clear obstructions from grilles. Recalibrate or replace thermostat. |
| Ашиглалтын явцад ер бусын үнэр гарч ирдэг. | Initial burn-off of manufacturing residues. Халаалтын элемент дээр тоос хуримтлагдах. | Ensure ventilation; odor should dissipate. Clean heater as per maintenance section. |
Хэрэв эдгээр шийдлүүдийг туршиж үзсэний дараа асуудал арилахгүй бол Stelpro хэрэглэгчийн дэмжлэг эсвэл мэргэшсэн цахилгаанчинтай холбогдоно уу.
Үзүүлэлтүүд
| Онцлог | Дэлгэрэнгүй |
|---|---|
| Брэнд | Стелпро |
| Загварын дугаар | ASHC1502WCW |
| Ватtage | 1500W (at 240V) / 1125W (at 208V) |
| Ботьtage | 240 вольт |
| Ampарилгах | 6.25 Amps |
| Бүтээгдэхүүний хэмжээ (D x W x H) | 3.94" x 28.63" x 17.56" (101мм x 727мм x 446мм) |
| Зүйлийн жин | 15.7 фунт |
| Халаалтын хамрах хүрээ | Up to 150 sq feet |
| Онцлог шинж чанарууд | Energy Efficient, Fast Heating, Noiseless |
| Form Factor | Засгийн газрын танхим |
| Өнгө | Цагаан |
| Суурилуулах төрөл | Ханын бэхэлгээ |
| Шатахууны төрөл | Цахилгаан |
| Дотор/гадаа ашиглах | Дотор |
| UPC | 626296203491 |

Баталгаат хугацаа
The Stelpro Ultra-Quiet Wall Convector Heater (Model ASHC1502WCW) is backed by a comprehensive warranty:
- 5 жилийн хязгаарлагдмал баталгаат хугацаа бүхэл бүтэн нэгж дээр.
- Насан туршийн баталгаа халаалтын элемент дээр.
- 3 жилийн баталгаат хугацаа on electronic components.
Please retain your proof of purchase for warranty claims. For full warranty terms and conditions, refer to the documentation included with your product or visit the official Stelpro webсайт.

Дэмжлэг
For technical assistance, warranty inquiries, or to purchase replacement parts, please contact Stelpro customer service.
You can find more information and contact details on the official Stelpro webсайт: Visit the Stelpro Store on Amazon
When contacting support, please have your model number (ASHC1502WCW) and proof of purchase readily available.
